SPECS

• neck type
• AS ArtcoreNyatohset-in neck
• top/back/side
• Linden top Linden backLinden sides
• fretboard
• Bound Rosewood fretboardAcrylic block inlay
• fret
• Medium frets
• number of frets
• 22
• bridge
• Gibraltar Performer bridge
• string space
• 10.5mm
• tailpiece
• Quik Change III tailpiece
• neck pickup
• Classic Elite (H) neck pickupPassive/Ceramic
• bridge pickup
• Classic Elite (H) bridge pickupPassive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL140
• string gauge
• .010/.013/.017/.030/.042/.052
• hardware color
• Chrome

NECK DIMENSIONS

• • Scale :
  • 628mm
  • a : Width
  • 43mm at NUT
  • b : Width
  • 57mm at 22F
  • c : Thickness
  • 21mm at 1F
  • d : Thickness
  • 24mm at 9F
  • Radius :
  • 305mmR

BODY DIMENSIONS

• • a : Length
  • 19 1/4"
  • b : Width
  • 15 3/4"
  • c : Max Depth
  • 2 5/8"

SWITCHING SYSTEM

CONTROLS

Features

Nyatoh neck

The Nyatoh neck provides a rich mid-low end.

Gibraltar Performer bridge

The Gibraltar Performer bridge provides rich sustain and tuning stability. The low-positioned saddles promise comfortable playability.

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Classic Elite pickups

The Classic Elite pickups offer rich, nuanced tone with fat low-end.

Quik Change III Tailpiece

The Quik Change III tailpiece enables faster and easier string changing.
