neck type    AZ Oval CS-TECH WOOD Roasted Maple neck
top/back/body    Ash body
fretboard    S-TECH WOOD Roasted Maple fretboardBlack dot inlay
fret    Jumbo Stainless Steel fretsPrestige fret edge treatment
number of frets    22
bridge    Gotoh® F1803 bridge
string space    10.5mm
neck pickup    Seymour Duncan® Magic Touch-mini™ (H) neck pickupPassive/Alnico
bridge pickup    Seymour Duncan® Alnico II Pro™ Custom (S) bridge pickupPassive/Alnico
factory tuning    1E,2B,3G,4D,5A,6E
strings    D'Addario® EXL110
string gauge    .010/.013/.017/.026/.036/.046
nut    Bone nut
hardware color    Chrome

Scale :    648mm/25.5"
a : Width    42mm at NUT
b : Width    56.4mm at 22F
c : Thickness    20.5mm at 1F
d : Thickness    22.5mm at 12F
Radius :    305mmR

SWITCHING SYSTEM
