SPECS

• neck type
• SR45pc Maple/Walnut neck
• top/back/body
• Nyatoh body
• fretboard
• Jatoba fretboardWhite dot inlay
• fret
• Medium frets
• number of frets
• 24
• bridge
• Accu-cast B120 bridge
• string space
• 19mm
• neck pickup
• PowerSpan Dual Coil neck pickupPassive
• bridge pickup
• PowerSpan Dual Coil bridge pickupPassive
• equalizer
• Ibanez Custom Electronics 3-band EQ w/3-way Power Tap switch
• factory tuning
• 1G,2D,3A,4E
• strings
• D'Addario® EXL165
• string gauge
• .045/.065/.085/.105
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 864mm/34"
  • a : Width
  • 38mm at NUT
  • b : Width
  • 62mm at 24F
  • c : Thickness
  • 19.5mm at 1F
  • d : Thickness
  • 21.5mm at 12F
  • Radius :
  • 305mmR

CONTROLS

FREQUENCY RESPONSE

Features

5pc Maple/Walnut neck

The 5pc Maple/Walnut neck provides tonal clarity and superior attack.

PowerSpan Dual Coil pickups

Developed by Ibanez, the exposed pole pieces of the PowerSpan Dual Coil pickups produce a stronger signal and increase the response of the higher frequencies without sacrificing low end. The result is a tone rich in harmonic detail and dynamic expression.

Ibanez Custom Electronics 3-band EQ w/3-way Power Tap switch

The 3-band EQ works in conjunction with a coil tap switch for maximum control over a wide variety of professional bass tones. Tap Mode (single coil) creates a punchy, dynamic sound with superior articulation. Series Mode (humbucking) delivers a full, warm tone, and Power Tap Mode provides the best of both worlds-combining the clarity of the single coil with the fat bottom end of the humbucker.

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
