SPECS

• neck type

  BTB5 for Multi Scale5pc Maple/Walnut w/Graphite reinforcement rodsNeck-through

• top/back/body

  Okoume wing body

• fretboard

  Rosewood fretboardAbalone dot inlay

• fret

  Medium Stainless Steel frets

• number of frets

  24 (+ zero fret)

• bridge

  MR5S bridge

• string space

  19mm

• neck pickup

  T1 neck pickupPassive

• bridge pickup

  T1 bridge pickupPassive

• equalizer

  Ibanez Custom Electronics 3-band EQ w/EQ bypass switch (passive tone control on treble pot), 3-way Mid frequency switch

• factory tuning

  1G,2D,3A,4E,5B

• strings

  D'Addario® NYXL45130SL

• string gauge

  .045/.065/.080/.100/.130

• hardware color

  Gold

NECK DIMENSIONS

• • Scale :

    889mm/35" - 864mm/34"

  • a : Width

    47mm at NUT

  • b : Width

    75mm at 24F

  • c : Thickness

    20mm at 1F

  • d : Thickness

    22mm at 12F

  • Radius :

    400mmR

CONTROLS

FREQUENCY RESPONSE

Features

5pc Maple/Walnut neck with Graphite reinforcement rods

The 5pc Maple/Walnut neck provides tonal clarity and superior attack.The Graphite reinforcement rods provides massive sustain and excellent stability.

Neck-through construction

The neck-through construction contributes to massive sustain and smooth access to high fretboard positions.

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Medium Stainless Steel frets

The Stainless Steel frets are durable and long-lasting.

Okoume wing body

The Okoume wing body provides a bright and solid sound.

T1 pickups

The T1 pickup is a humbucker featuring two separate, individually mounted coils that provides tight bass response, punchy mid-range, and clear high-end. It offers flexible voicing suitable for various genres, and the height of each coil can be set individually for highly nuanced adjustments to the tone. On top of its great sound, the physical design features rounded edges for enhanced ergonomic comfort when using the pickup as a thumb rest. Moreover, the individually mounted coils allow them to be positioned slightly offset from one another. This makes it so the surface of the pickup where the player rests their thumb is directly parallel with the strings, which is not typical with most multi scale basses. This design greatly enhances the comfort and playability of the instrument.

Ibanez Custom Electronics 3-band EQ w/EQ bypass switch & Mid frequency switch

Ibanez Custom Electronics 3-band EQ is our latest refinement on the concept of simple, straightforward, no-nonsense EQ control. The Boost and Cut for the Mid Control are each centered on slightly different frequencies, an innovation that delivers a preset range of the most favorable bass tones.
Precision tonal control, including a switch to choose passive-only operation. When the EQ bypasses activated, the treble tone control knob becomes the global tone control for the passive circuit.

MR5S bridge

The MR5S bridge has adjustable saddles for variable string spacing by +/- 1.5mm, answering every bassist's specific string spacing needs.

35-34 inch multi scale

35-34 inch multi scale construction allows the higher strings to be played more easily, while still having adequate tension for lower strings.
