SPECS

• neck type
• GRGMaple neck
• top/back/body
• Quilted Maple Art Grain (Basswood) topPoplar body
• fretboard
• Bound Purpleheart fretboardWhite dot inlay
• fret
• Medium frets
• number of frets
• 24
• bridge
• T102 bridge
• string space
• 10.5mm
• neck pickup
• Infinity R (H) neck pickupPassive/Ceramic
• bridge pickup
• Infinity R (H) bridge pickupPassive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E
• string gauge
• .009/.011/.016/.024/.032/.042
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 58mm at 24F
  • c : Thickness
  • 19.5mm at 1F
  • d : Thickness
  • 21.5mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Maple neck

The Maple neck provides stability and bright tonal character.

T102 tremolo

The T102 bridge with 10.5mm string spacing allows easier picking across strings.

Purpleheart fretboard

The Purpleheart fretboard emphasizes the beauty and the rich tonal character of this guitar.

Mono-unit output jack

The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.

Infinity R H-H pickups

Ibanez Infinity pickups deliver an accurate and tight sound with excellent dynamics. Even under heavy settings, they do not lose tonal clarity.
