SPECS

• neck type
• BTB5 for Multi Scale5pc Maple/Walnut w/Graphite reinforcement rodsNeck-through
• top/back/body
• Okoume wing body
• fretboard
• Flamed Maple fretboardAbalone dot inlay
• fret
• Medium Stainless Steel frets
• number of frets24 (+ zero fret)
• bridge
• MR5S bridge
• string space
• 19mm
• neck pickup
• T1 neck pickupPassive
• bridge pickup
• T1 bridge pickupPassive
• equalizer
• Ibanez Custom Electronics 3-band EQ w/EQ bypass switch (passive tone control on treble pot), 3-way Mid frequency switch
• factory tuning
• 1G,2D,3A,4E,5B
• strings
• D'Addario® NYXL45130SL
• string gauge
• .045/.065/.080/.100/.130
• hardware color
• Gold

NECK DIMENSIONS

• • Scale :
  • 889mm/35" - 864mm/34"
  • a : Width
  • 47mm at NUT
  • b : Width
  • 75mm at 24F
  • c : Thickness
  • 20mm at 1F
  • d : Thickness
  • 22mm at 12F
  • Radius :
  • 400mmR

CONTROLS

FREQUENCY RESPONSE

Features

5pc Maple/Walnut neck with Graphite reinforcement rods

The 5pc Maple/Walnut neck provides tonal clarity and superior attack.The Graphite reinforcement rods provides massive sustain and excellent stability.

Neck-through construction

The neck-through construction contributes to massive sustain and smooth access to high fretboard positions.

Flamed Maple fretboard

The beautiful Flamed Maple fretboard imbues this model with an exotic appearance.

Medium Stainless Steel frets

The Stainless Steel frets are durable and long-lasting.

Okoume wing body

The Okoume wing body provides a bright and solid sound.

T1 pickups

The T1 pickup is a humbucker featuring two separate, individually mounted coils that provides tight bass response, punchy mid-range, and clear high-end. It offers flexible voicing suitable for various genres, and the height of each coil can be set individually for highly nuanced adjustments to the tone. On top of its great sound, the physical design features rounded edges for enhanced ergonomic comfort when using the pickup as a thumb rest. Moreover, the individually mounted coils allow them to be positioned slightly offset from one another. This makes it so the surface of the pickup where the player rests their thumb is directly parallel with the strings, which is not typical with most multi scale basses. This design greatly enhances the comfort and playability of the instrument.

Ibanez Custom Electronics 3-band EQ w/Mid frequency switch

Ibanez Custom Electronics 3-band EQ is our latest refinement on the concept of simple, straightforward, no-nonsense EQ control. The Boost and Cut for the Mid Control are each centered on slightly different frequencies, an innovation that delivers a preset range of the most favorable bass tones.

MR5S bridge

The MR5S bridge has adjustable saddles for variable string spacing by +/1.5mm, answering every bassist’s specific string spacing needs.

3-way Mid frequency switch

The 3-way Mid frequency switch allow players to change the mid-tone between 250, 450, and 700 Hz.

35-34 inch multi scale

35-34 inch multi scale construction allows the higher strings to be played more easily, while still having adequate tension for lower strings.
