SPECS

• neck type
• JS1pc Maple neck
• top/back/body
• Basswood body
• fretboard
• Rosewood fretboardMother of Pearl dot inlay
• fret
• Medium fretsPrestige fret edge treatment
• number of frets
• 22
• bridge
• Edge bridge
• string space
• 10.8mm
• neck pickup
• DiMarzio® PAF Pro® (H) neck pickupPassive/Alnico
• bridge pickup
• DiMarzio® Satchur8™ (H) bridge pickupPassive/Alnico
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL120
• string gauge
• .009/.011/.016/.024/.032/.042
• nut
• Locking nut
• hardware color
• Chrome

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 42.8mm at NUT
  • b : Width
  • 56.4mm at 21F
  • c : Thickness
  • 20mm at 1F
  • d : Thickness
  • 22.3mm at 12F
  • Radius :
  • 250mmR

SWITCHING SYSTEM

CONTROLS

Features

Maple neck

The Maple neck provides stability and bright tonal character.

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Medium frets with Prestige fret edge treatment

Medium sized frets enhance the accuracy of your notes. Prestige Fret Edge Treatment guarantees effortlessly fast playing.

DiMarzio® PAF Pro® / DiMarzio® Satchur8™ pickups

The DiMarzio® PAF Pro® pickups produce an open and clean low end with a carefully tweaked treble side that helps cut through the mix. DiMarzio® Satchur8™ pickup fully supports Joe's versatile playing style and massive sound.

Gotoh® machine heads

Gotoh® machine heads provide superior precision, a smooth feel, and excellent tuning accuracy.

Edge tremolo

The masterpiece Edge bridge offers exceptional tuning stability, precise intonation adjustment, and playing comfort.

High-Pass filter on volume control

A high pass filter on the volume pot maintains highs at low volumes.

Coil-tap switch on tone control (push/pull)

The push/pull coil tap adds sound and tonal variations for pickups.

Chrome Finish
