PRODUCT OVERVIEW
neck type AS Artcore NyatohSet-in neck
top/back/side Linden top Linden backLinden sides
fretboard Bound Laurel fretboardAged Acrylic block inlay
fret Medium frets
number of frets 22
bridge ART-1 bridge
tailpiece Quik Change III
neck pickup Classic Elite (H) neck pickupPassive/Ceramic
bridge pickup Classic Elite (H) bridge pickupPassive/Ceramic
factory tuning 1E,2B,3G,4D,5A,6E
string gauge .010/.013/.017/.030/.042/.052
nut Plastic
hardware color Antique Chrome
Scale : 628mm/24.7"
a : Width 43mm at NUT
b : Width 57mm at 22F
c : Thickness 21mm at 1F
d : Thickness 24mm at 9F
Radius : 305mmR
BODY DIMENSIONS
a : Length 19 1/4"
b : Width 15 3/4"
c : Max Depth 2 5/8"
SWITCHING SYSTEM
CONTROLS
