neck type    AM Expressionist3pc Nyatoh/MapleSet-in neck
top/back/side    Linden top Linden backLinden sides
fretboard    Bound Macassar Ebony fretboardAbalone dot inlay
fret    Medium frets
number of frets    22
bridge    Gibraltar Performer bridge
string space    10.5mm
tailpiece    VT06 tailpiece
neck pickup    Super 58 (H) neck pickupPassive/Alnico
bridge pickup    Super 58 (H) bridge pickupPassive/Alnico
factory tuning    1E,2B,3G,4D,5A,6E
string gauge    .010/.013/.017/.030/.042/.052
hardware color    Gold

Scale :    628mm
a : Width    43mm at NUT
b : Width    57mm at 22F
c : Thickness    21mm at 1F
d : Thickness    24mm at 9F
Radius :    305mmR
