SPECS

• neck type
• Wizard III5pc Maple/WalnutNeck-through

• top/back/body
• Nyatoh wing body

• fretboard
• Jatoba fretboardWhite dot inlay
• fret
• Jumbo frets
• number of frets
• 24
• bridge
• Edge-Zero II bridge
• string space
• 10.8mm
• neck pickup
• Quantum (H) neck pickupPassive/Ceramic
• bridge pickup
• Quantum (H) bridge pickupPassive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL120
• string gauge
• .009/.011/.016/.024/.032/.042
• nut
• Locking nut
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 58mm at 24F
  • c : Thickness
  • 19mm at 1F
  • d : Thickness
  • 21mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.

Neck-through Construction

Neck-through construction provides massive sustain and playing comfort.

Edge-Zero II tremolo bridge

The Edge Zero II bridge design features a lower profile tremolo for playing comfort and stud lock function for stable tuning.

Wizard III 5pc Maple/Walnut neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability and features a two-octave 24-fret fretboard for a wide tonal range.

Quantum pickups

The Quantum pickups provide accelerated bass response for exceptionally fast tracking of high-speed staccato riffing with crushing mid range and precise high-end articulation.
