SPECS

• neck type
• SRD55pc Maple/Walnut neck
• top/back/body
• Exotic Maple topOkoume body
• fretboard
• Bound Panga Panga fretboardAbalone oval inlay
• fret
• Medium frets
• bridge
• AeroSilk MR5 bridge
• string space
• 16.5mm
• neck pickup
• Nordstrand™ Big Break neck pickupPassive
• bridge pickup
• Nordstrand™ Big Break bridge pickupPassive
• equaliser
• Ibanez 2-band EQ w/Piezo active tone control
• factory tuning
• 1G,2D,3A,4E,5B
• strings
• D'Addario® ECB81-5 Flatwound
• string gauge
• .045/.065/.085/.105/.130
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 864mm/34"
  • a : Width
  • 45mm at NUT
  • b : Width
  • 68mm at 30F
  • c : Thickness
  • 21.5mm at 1F
  • d : Thickness
  • 23.5mm at 12F
  • Radius :
  • 305mmR

CONTROLS

FREQUENCY RESPONSE

Features

5pc Maple/Walnut neck

The 5pc Maple/Walnut neck provides tonal clarity and superior attack.

30 Fret Neck

It has an extended 30-fret fretboard for playing upper register notes usually only accessible on an upright.

Panga Panga fretboard

Panga Panga features a beautiful wood grain which produces a tight low and mid range, along with a sharp attack on high end.

Exotic Maple top / Okoume body

A beautiful Flamed Maple top over an Okoume body provides a bright and powerful sound.

Nordstrand™ Big Break / AeroSilk piezo pickups

Nordstrand™ "Big Break" pickups cram a powerful split coil into a soapbar-style pickup, producing a full-bodied, powerful, aggressive tonal texture, while retaining the clarity that's characteristic of single coil tone with noiseless performance. The custom bridge contains the magic of the AeroSilk Piezo system to provide that sense of "air" that characterizes upright sound.

Ibanez 2-band EQ w/Piezo active tone control

The EQ section incorporates the controls of the magnetic pickup(s) with the AeroSilk Piezo system. Controls include a Master volume, bass and treble controls for the pickup(s) and a Master volume and a tone control for the Piezo system.

AeroSilk MR5 bridge

The AeroSilk MR5 bridge has unique saddles which were specifically-designed to work in concert with the piezo pickups, enhancing the acoustic "Upright" quality of the tone.

Luminescent side dot inlays

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
