SPECS

• neck type
• EHB59pc Panga Panga/Walnut w/Graphite reinforcement rods
• top/back/body
• Pale Moon Ebony topAsh body
• fretboard
• Bound Panga Panga fretboardOff-set Abalone dot inlay
• fret
• Medium Stainless Steel frets
• number of frets
• 24
• bridge
• MR5HS bridge
• string space
• 18mm
• neck pickup
• Fishman® Fluence™ neck pickupActive
• bridge pickup
• Fishman® Fluence™ bridge pickupActive
• equaliser
• Fishman® 3-band EQ w/Single Coil Mode switch (push/pull), 3-way Voice Select switch
• factory tuning
• 1G,2D,3A,4E,5B
• strings
• D'Addario® EXL170-5SL
• string gauge
• .045/.065/.080/.100/.130
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 889mm/35" - 838mm/33"
  • a : Width
  • 45mm at NUT
  • b : Width
  • 74mm at 24F
  • c : Thickness
  • 19.5mm at 1F
  • d : Thickness
  • 21.5mm at 12F
  • Radius :
  • 500mmR

CONTROLS

FREQUENCY RESPONSE

Features

Ergonomic body design

The EHB’s headless construction and specially designed body enable the player to maintain a similar playing position whether seated or standing.

Slanted body back

The top half of the back of the body is slanted which allows the bass to rest slightly closer to the player’s body for better control and a more ergonomic feel.

Pale Moon Ebony top / Ash body

The Pale Moon Ebony top displays a rich, beautiful wood grain, and the Ash body delivers a pleasant brightness with rich sustain.

Fishman® Fluence™ pickups

These Fishman® Fluence™ pickups are the first for bass to feature stainless covers. These unique pickups deliver Fluence Multi-Voice performance, impressive dynamic range, and outstanding articulation with no extraneous noise.

Fishman® 3-band EQ w/Single Coil Mode switch (push/pull), 3-way Voice Select switch

This new EQ was developed by Fishman® for Ibanez and is built around a newly added mid control. The center frequency for the mid control is 630Hz.
The Single Coil Mode switch adds even more tonal flexibility to pickups.
The Voice Selector switch offers players a wide palette of sounds to cover all playing styles.
Voice 1 (Passive): Classic, fat and round
Voice 2 (Active): Full frequency, full dynamics
Voice 2 (Active with mid contour): Funk, Hi-Fi scooped
Single Coil Mode: Same voices as above but with a narrower magnetic field

Ibanez custom headpieces

Rugged yet light-weight Ibanez custom headpieces enable strings to be easily set and released by a hex wrench from the back side.

Comfortably rounded body edge, Chambered body

Its contoured, ergonomic design and chambered body make for a lightweight, well-balanced, and comfortable instrument that’s excellent for long sets or practice session.

Scooped cut on the body back

There is extra carving on the back of the body behind the lower horn for easier upper fret access.

9pc Panga Panga/Walnut neck w/Graphite reinforcement rods

The 9-piece Panga Panga/Walnut neck provides superior note attack, tight lows and increased sustain with the Panga Panga fretboard.

MR5HS mono rail bridge w/string spacing adjustable saddles

The MR5HS bridge is designed especially for the EHB basses and features wide intonation range. Each bridge piece is independently and securely attached to the body for maximum vibration transfer, and the saddles are adjustable for string spacing +/-1.5mm, answering every bassist’s individual string spacing demands, no matter what playing style. Teflon washers are used on each tuner for a smooth tuning action.

Schaller S-Locks strap pins and Neutrik locking jack

Schaller S-Lock strap lock pins and a Neutrik locking jack hold the strap and cable securely.

Detachable Finger ramp

A detachable Finger ramp is included for comfortable finger picking.

Panga Panga fretboard

Panga Panga features a beautiful wood grain which produces a tight low and mid range, along with a sharp attack on high end.

Luminescent side dot inlays

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
