SPECS

• body shape
• Asymmetrical Jumbo body
• bracing
• Thermo Aged™ Spruce Modified X-M Bracing
• top
• Thermo Aged™ Solid Sitka Spruce top
• back & sides
• Solid African Mahogany back & Solid African Mahogany sides
• neck
• JGMAfrican Mahogany/Maple 5pc neck
• fretboard
• Macassar Ebony fretboard
• bridge
• Macassar Ebony top loading bridge
• body binding
• Macassar Ebony body binding with rounded body edge
• top board purfling
• Wooden
• inlay
• Specially designed "PASSIONFLOWER” Wooden Vine inlay
• soundhole rosette
• Specially designed "Mobius ring" wooden rosette
• tuning machine
• Gotoh® Chrome SGS510Z tuners (18:1 gear ratio), Keith Banjo Tuners Stainless Steel D-Tuners 1/2
• nut material
• Bone
• number of frets
• 20
• saddle material
• Bone
• strings
• D'Addario® XTAPB1256
• string gauge
• .012/.016/.025/.035/.045/.056
• string space
• 11.7mm
• factory tuning
• 1D,2A,3G,4D,5G,6C
• pickup
• Fishman® Rare Earth Mic Blend Active Soundhole, Tap
• preamp
• Fishman® PowerTap Earth Blend preamp
• output jack
• Dual Outputs (2 endpin jacks - 1 stereo/mono output capability built in (with strap button) - 1 mono flush mount)
• battery
• 9V x1

NECK DIMENSIONS

• • Scale :
  • 655mm/25.75"
  • a : Width
  • 45mm at NUT
  • b : Width
  • 60mm at 14F
  • c : Thickness
  • 20.5mm at 1F
  • d : Thickness
  • 22mm at 7F
  • Radius :
  • 400mmR
