SPECS

• neck type
• SR65pc Maple/Walnut neck
• top/back/body
• Okoume body
• fretboard
• Jatoba fretboardWhite dot inlay
• fret
• Medium frets
• number of frets
• 24
• bridge
• Accu-cast B126 bridge
• string space
• 16.5mm
• neck pickup
• PowerSpan Dual Coil neck pickupPassive
• bridge pickup
• PowerSpan Dual Coil bridge pickupPassive
• equalizer
• Ibanez Custom Electronics 3-band EQ w/3-way Power Tap switch
• factory tuning
• 1C,2G,3D,4A,5E,6B
• strings
• D'Addario® EXL165 + .032/.130
• string gauge
• .032/.045/.065/.085/.105/.130
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 864mm/34"
  • a : Width
  • 54mm at NUT
  • b : Width
  • 83mm at 24F
  • c : Thickness
  • 19.5mm at 1F
  • d : Thickness
  • 21.5mm at 12F
  • Radius :
  • 400mmR

CONTROLS

FREQUENCY RESPONSE

Features

5pc Maple/Walnut neck

The 5pc Maple/Walnut neck provides tonal clarity and superior attack.

Accu-cast B120 Bridge

The B120's extra-wide string slots can accommodate even the heaviest of gauges. The walls and channels of the new bridge plate effectively ”trap” the saddles, ensuring perfect directional uniformity.

PowerSpan Dual Coil pickups

Developed by Ibanez, the exposed pole pieces of the PowerSpan Dual Coil pickups produce a stronger signal and increase the response of the higher frequencies without sacrificing low end. The result is a tone rich in harmonic detail and dynamic expression.

Ibanez Custom Electronics 3-band EQ w/3-way Power Tap switch

The 3-band EQ works in conjunction with a coil tap switch for maximum control over a wide variety of professional bass tones. Tap Mode (single coil) creates a punchy, dynamic sound with superior articulation. Series Mode (humbucking) delivers a full, warm tone, and Power Tap Mode provides the best of both worlds-combining the clarity of the single coil with the fat bottom end of the humbucker.

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.

Okoume body

The Okoume body provides a bright and solid sound.

Medium frets

Medium sized frets enhance the accuracy of your notes.
