neck type    GRGMaple neck
top/back/body    Quilted Maple Art Grain topPoplar body
fretboard    Bound Purpleheart fretboardWhite dot inlay
fret    Jumbo frets
number of frets    24
bridge    T102 bridge
string space    10.5mm
neck pickup    Infinity R (H) neck pickupPassive/Ceramic
bridge pickup    Infinity R (H) bridge pickupPassive/Ceramic
factory tuning    1E,2B,3G,4D,5A,6E
string gauge    .009/.011/.016/.024/.032/.042
hardware color    Black

NECK DIMENSIONS
Scale :    648mm/25.5"
a : Width    43mm at NUT
b : Width    58mm at 24F
c : Thickness    19.5mm at 1F
d : Thickness    21.5mm at 12F
Radius :    400mmR
