SPEC
neck type    TMB5Maple neck
top/back/body    Poplar body
fretboard    Jatoba fretboardWhite dot inlay
fret    Medium frets
number of frets    20
bridge    B15W bridge
string space    18mm
neck pickup    Dynamix P neck pickupPassive
bridge pickup    Dynamix J bridge pickupPassive
factory tuning    1G,2D,3A,4E,5B
string gauge    .045/.065/.085/.105/.130
hardware color    Chrome

NECK DIMENSIONS
Scale :    762mm/30"
a : Width    45mm at NUT
b : Width    72mm at 20F
c : Thickness    21.5mm at 1F
d : Thickness    24.5mm at 12F
Radius :    305mmR

CONTROLS
