SPEC
neck type    JS3pc Maple/Bubinga neck
top/back/body    Basswood body
fretboard    RosewoodMother of Pearl dot inlay
fret    Medium fretsPrestige fret edge treatment
bridge    Edge tremolo bridge
neck pickup    SUSTAINIAC® Driver (S) neck pickup
bridge pickup    DiMarzio® Satchur8™ (H) bridge pickup Passive/Alnico
factory tuning    1E, 2B, 3G, 4D, 5A, 6E
string gauge    .009/.011/.016/.024/.032/.042
hardware color    Chrome

NECK DIMENSIONS
Scale :    648mm/25.5"
a : Width    42.8mm at NUT
b : Width    56.4mm at 21F
c : Thickness    20mm at 1F
d : Thickness    22.3mm at 12F
Radius :    250mmR

SWITCHING SYSTEM

CONTROLS
