SPECS

• neck type
• GRGMaple neck
• top/back/body
• Poplar body
• fretboard
• Bound Purpleheart fretboardRed Sharktooth inlay
• fret
• Medium frets
• number of frets
• 24
• bridge
• F106 bridge
• string space
• 10.5mm
• neck pickup
• Infinity R (H) neck pickupPassive/Ceramic
• bridge pickup
• Infinity R (H) bridge pickupPassive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E
• string gauge
• .010/.013/.017/.026/.036/.046
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 58mm at 24F
  • c : Thickness
  • 19.5mm at 1F
  • d : Thickness
  • 21.5mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Maple neck

The Maple neck provides stability and bright tonal character.

Purpleheart fretboard

The Purpleheart fretboard emphasizes the beauty and the rich tonal character of this guitar.

Mono-unit output jack

The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.

F106 bridge

The F106 bridge enriches sustain. String height adjustment can be done easily and independently.

Infinity R H-H pickups

Ibanez Infinity pickups deliver an accurate and tight sound with excellent dynamics. Even under heavy settings, they do not lose tonal clarity.
