SPEC
neck type    TMB4  Maple neck
top/back/body    Poplar body
fretboard    JatobaWhite dot inlay
fret    Medium frets
bridge    B10 bridge
string space    19mm
neck pickup    Dynamix P neck pickupPassive
bridge pickup    Dynamix J bridge pickupPassive
equaliser    Ibanez Custom Electronics 2-band EQ
hardware color    Chrome

NECK DIMENSIONS
Scale :    864mm/34"
a : Width    41mm at NUT
b : Width    62mm at 20F
c : Thickness    21.5mm at 1F
d : Thickness    24.5mm at 12F
Radius :    240mmR

CONTROLS

FREQUENCY RESPONSE
