SPECS

• neck type
• GRGMMaple neck
• top/back/body
• Poplar body
• fretboard
• Maple fretboardBlack dot inlay
• fret
• Medium frets
• number of frets
• 24
• bridge
• F106 bridge
• string space
• 10.5mm
• neck pickup
• Infinity R (H) neck pickupPassive/Ceramic
• bridge pickup
• Infinity R (H) bridge pickupPassive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E
• string gauge
• .010/.013/.017/.026/.036/.046
• hardware color
• Chrome

NECK DIMENSIONS

• • Scale :
  • 564mm/22.2"
  • a : Width
  • 41mm at NUT
  • b : Width
  • 56mm at 24F
  • c : Thickness
  • 19.5mm at 1F
  • d : Thickness
  • 21.5mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Maple neck

The Maple neck provides stability and bright tonal character.

Maple fretboard

The Maple fretboard provide crisp, bright highs and strong upper mids.

F106 bridge

The F106 bridge enriches sustain. String height adjustment can be done easily and independently.

Infinity R H-H pickups

Ibanez Infinity pickups deliver an accurate and tight sound with excellent dynamics. Even under heavy settings, they do not lose tonal clarity.
