SPECS

• neck type

  AZ Oval CRoasted Maple neck

• top/back/body

  American Basswood body

• fretboard

  Ebony fretboard

• fret

  Jumbo Stainless Steel frets

• number of frets

  24

• bridge

  F106 bridge

• string space

  10.5mm

• neck pickup

  DiMarzio® Fusion Edge (H) neck pickupPassive/Ceramic

• bridge pickup

  DiMarzio® Fusion Edge (H) bridge pickupPassive/Ceramic

• factory tuning

  1E,2B,3G,4D,5A,6E

• strings

  D'Addario® EXL110

• string gauge

  .010/.013/.017/.026/.036/.046

• nut

  Graph Tech® nut

• hardware color

  Black

NECK DIMENSIONS

• • Scale :

    648mm/25.5"

  • a : Width

    42mm at NUT

  • b : Width

    57mm at 24F

  • c : Thickness

    20.5mm at 1F

  • d : Thickness

    22.5mm at 12F

  • Radius :

    305mmR

SWITCHING SYSTEM

CONTROLS

Features

F106 bridge

The F106 bridge enriches sustain. String height adjustment can be done easily and independently.

Ebony fretboard

Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.

DiMarzio® Fusion Edge Pickups

Through close collaboration between Ibanez and DiMarzio® Fusion Edge pickups have been engineered to produce a powerful, distinctive tone with a crisp, cutting high end, and a tight, compressed bottom end, minus any muddy mid-range.

Gotoh® MG-T locking machine heads

The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.

American Basswood body

The American Basswood body delivers a natural and flat tone.

Oval C Roasted Maple neck

Heat-treatment increases the wood's stability, durability, water resistance and tolerance of temperature changes.

dyna-MIX10 switching system w/Alter switch

The dyna-MIX 10 offers ten sound variations and can easily switch from humbucker and single coil modes with the mini switch. The power Tap mode provides a realistic single coil sound despite its two humbucker pickup layout.

Ergonomic rear body contour

A shallow body back contour and a big forearm contour make the guitar body fit the player naturally, thus increasing playing comfort. The AZ body has a deep waist and different radii on each body edge curve, making it easier to play in both standing or sitting positions.

Super All Access Neck Joint

The Super All Access Neck Joint increases playability and allows for easy access to the higher frets.
