SPECS

• body shape
• Altstar body
• top
• Flamed Maple Art Grain (Basswood) top
• back & sides
• Sapele back & Sapele sides
• neck
• Comfort GripMaple neck
• fretboard
• Purpleheart fretboard
• bridge
• Purpleheart bridge
• inlay
• Sharktooth inlay
• Die-cast tuners (18:1 gear ratio)
• number of frets
• 22
• bridge pins
• Ibanez Advantage™
• strings
• Ibanez IACS61C
• string gauge
• .010/.014/.023/.030/.039/.047
• string space
• 10.5mm
• factory tuning
• 1E,2B,3G,4D,5A,6E
• pickup
• Ibanez Undersaddle
• preamp
• Ibanez AEQ-2T preamp w/Onboard tuner
• output jack
• 1/4" output
• battery
• 9V x1

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 55mm at 16F
  • c : Thickness
  • 20mm at 1F
  • d : Thickness
  • 21mm at 7F
  • Radius :
  • 400mmR

BODY DIMENSIONS

• • a : Length
  • 18 1/8"
  • b : Width
  • 14 5/8"
  • c : Max Depth
  • 4 3/8"

•

PREAMP

Features

Purpleheart fretboard

The Purpleheart fretboard emphasizes the beauty and the rich tonal character of this instrument.

Purpleheart bridge

The Purpleheart bridge transfers string vibration directly to the body, delivering a natural and warm tone.

Comfort Grip Maple neck

The Comfort Grip Maple Neck contour provides superior playability.

Ibanez AEQ-2T preamp w/Onboard tuner

AEQ-2T preamp is specifically-designed to adjust the frequencies of a bass and Treble, and allows operation of the built-in tuner without the instrument being plugged in.

Large frets

The large frets contribute to smooth playability, especially for phrasing involving a series of quick, successive notes.

Ibanez Advantage™ bridge pins

These pins really are an advantage over old-fashioned pins. Advantage™ pins are easier to take out and easier to put in than standard pins. A special bulb-shaped end makes the pin easy to grip and also prevents the pin from being pushed in too far. Best of all, with Advantage™ the pin and string stay put.
