SPECS

• neck type
• AS Artcore3pc Nyatoh/MapleSet-in neck
• top/back/side
• Linden top Linden backLinden sides
• fretboard
• Bound Rosewood fretboardAcrylic block inlay
• fret
• Medium frets
• number of frets
• 22
• bridge
• Gibraltar Performer bridge
• string space
• 10.5mm
• tailpiece
• VT06 tailpiece
• neck pickup
• Classic Elite (H) neck pickupPassive/Ceramic
• bridge pickup
• Classic Elite (H) bridge pickupPassive/Ceramic
• factory tuning
• 1B,2F#,3D,4A,5E,6B
• strings
• D'Addario® EXL157
• string gauge
• .014/.018/.026w/.044/.056/.068
• hardware color
• Chrome

NECK DIMENSIONS

• • Scale :
  • 711mm/28"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 57mm at 22F
  • c : Thickness
  • 21mm at 1F
  • d : Thickness
  • 24mm at 9F
  • Radius :
  • 305mmR

BODY DIMENSIONS

• • a : Length
  • 19 1/4"
  • b : Width
  • 15 3/4"
  • c : Max Depth
  • 2 5/8"

•

SWITCHING SYSTEM

CONTROLS

Features

Gibraltar Performer bridge

The Gibraltar Performer bridge provides rich sustain and tuning stability. The low-positioned saddles promise comfortable playability.

3pc Nyatoh/Maple neck

The 3pc Nyatoh/Maple Neck provides a rich mid-low end and great resonance.

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Classic Elite pickups

The Classic Elite pickups offer rich, nuanced tone with fat low-end.

VT06 tailpiece

The artistically-designed VT06 tailpiece provides both great tuning stability and rich sustain.

Linden top / Linden back and sides

Linden delivers a natural and flat, yet accurate, tone.
