SPECS

• neck type
• MDM4Roasted Maple neck
• top/back/body
• Alder body
• fretboard
• Rosewood fretboardWhite dot inlay
• fret
• Medium Stainless Steel frets
• number of frets
• 24
• bridge
• MR5S bridge
• string space
• 19mm
• neck pickup
• Delta S4J neck pickupPassive
• bridge pickup
• Delta S4J bridge pickupPassive
• equalizer
• Ibanez Sonitech S Preamp 3-band EQ w/EQ bypass switch (push/pull), 3-way Mid frequency switch w/Hexa Mid system
• factory tuning
• 1G,2D,3A,4E
• strings
• D'Addario® EXL165
• string gauge
• .045/.065/.085/.105
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 864mm/34"
  • a : Width
  • 38mm at NUT
  • b : Width
  • 62mm at 24F
  • c : Thickness
  • 20.5mm at 1F
  • d : Thickness
  • 22.5mm at 12F
  • Radius :
  • 305mmR

CONTROLS

FREQUENCY RESPONSE

Features

Roasted Maple neck

The Roasted Maple neck is heat-treated to increase stability, durability, moisture resistance and tolerance of temperature changes.

Delta S4J pickups

The Ibanez Delta pickups deliver an aggressive yet balanced single-coil tone that responds clearly and evenly in all frequency ranges. They're voiced to cut powerfully through any mix while eliminating noise, thanks to their hum-canceling design.

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Medium Stainless Steel frets

The Stainless Steel frets are durable and long-lasting.

Alder body

The Alder body delivers a well-balanced bright tone, enriched resonance and sustain.

Ibanez Aero-light machine heads

Ibanez Aero-light machine heads feature keys made of Extra Super Duralumin," which significantly reduces the overall weight of the tuning machine while still maintaining durability and tuning accuracy. These extremely lightweight tuners help facilitate excellent instrument balance, which is essential for comfort during long gigs.

MR5S bridge

The MR5S bridge has adjustable saddles for variable string spacing by +/- 1.5mm, answering every bassist's specific string spacing needs.

Ibanez Sonitech S Preamp 3-band EQ w/EQ bypass switch (push/pull)

The Ibanez Sonitech S Preamp boasts a meticulously tuned tonal character across the entire frequency spectrum. This circuit offers two selectable 3-band mid-range banks and a passive tone control for unparalleled versatility. The preamp is designed to deliver maximum flexibility and ease of use.
The EQ bypass switch (push/pull) switches between EQ bypass (Pull) or EQ on (Push).

3-way Mid frequency switch w/Hexa Mid system

The Hexa Mid system offers players the flexibility to choose from two mid-range banks, each containing three distinct frequency points, for a total of six. Its exceptional versatility and user-friendly interface help players achieve their ideal bass sound.

Super All Access Neck Joint

The Super All Access Neck Joint increases playability and allows for easy access to the higher frets.

MDM body shape

The MDM body is designed for perfect balance and smooth access to all 24 frets.

Luminescent side dot inlays

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
