SPECS

• neck type
• Wizard III5pc Maple/Walnut neckNeck-through
• top/back/body
• Okoume wing body
• fretboard
• Rosewood fretboardReversed Sharktooth inlay
• fret
• Jumbo frets
• number of frets
• 24
• bridge
• Edge-Zero II bridge
• string space
• 10.8mm
• neck pickupQuantum (H) neck pickupPassive/Ceramic
• bridge pickup
• Quantum (H) bridge pickupPassive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL120
• string gauge
• .009/.011/.016/.024/.032/.042
• nut
• Locking nut
• hardware color
• Cosmo Black

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 58mm at 24F
  • c : Thickness
  • 19mm at 1F
  • d : Thickness
  • 21mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Wizard III 5pc Maple/Walnut neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability for demanding players.

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Jumbo frets

Jumbo frets contribute to smooth playability, especially for single-note playing.

Okoume wing body

The Okoume wing body provides a bright and solid sound.

Quantum H-H pickups

The Quantum pickups have a quick low-end response to picking and are able to capture fast passages with precise note definition, while delivering a full-bodied mid-to-high range.

Edge-Zero II tremolo

The Edge Zero II bridge design features a lower profile tremolo for playing comfort and stud lock function for stable tuning.
