SPECS

• neck type
• Wizard III5pc Panga Panga/Walnut neck
• top/back/body
• Ash topOkoume body
• fretboard
• Macassar Ebony fretboardWhite Step off-set dot inlay
• fret
• Jumbo frets
• number of frets
• 24
• bridge
• Gibraltar Standard III bridge
• string space
• 10.8mm
• neck pickup
• DiMarzio® Fusion Edge (H) neck pickupPassive/Ceramic
• bridge pickup
• DiMarzio® Fusion Edge (H) bridge pickupPassive/Ceramic
• factory tuning
• 1D,2A,3F,4C,5G,6D
• strings
• D'Addario® EXL110
• string gauge
• .010/.013/.017/.026/.036/.046
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 673mm/26.5"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 58mm at 24F
  • c : Thickness
  • 19mm at 1F
  • d : Thickness
  • 21mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Macassar Ebony fretboard

Macassar Ebony produces tight lows and mid range along with strong attack in the highs and quick response with rich sustain.

Ash top / Okoume body

The Ash top imbues this bass with an exotic appearance and the Okoume body delivers a rich mid-low end.

Gibraltar Standard III bridge

The Gibraltar Standard III bridge, featuring a redesigned baseplate and saddles, offers enhanced playing comfort while ensuring optimal string vibration transfer.

Luminescent side dot inlays

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.

Wizard III 5pc Panga Panga/Walnut neck

The Super-thin and ultra-playable Wizard III 5-piece Panga Panga/Walnut neck substantially increases sustain.

Coil-tap switch

The coil tap switch adds sound and tonal variations for both pickups.

DiMarzio® Fusion Edge Pickups

Through close collaboration between Ibanez and DiMarzio® Fusion Edge pickups have been engineered to produce a powerful, distinctive tone with a crisp, cutting high end, and a tight, compressed bottom end, minus any muddy mid-range.

Gotoh® MG-T locking machine heads

The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.
