SPECS

• neck type
• Wizard II-73pc Maple neck
• top/back/body
• Meranti body
• fretboard
• Jatoba fretboardOff-set white dot inlay
• fret
• Jumbo frets
• number of frets
• 24
• bridge
• F107 bridge
• string space
• 10.5mm
• neck pickup
• Quantum 7 (H) neck pickupPassive/Ceramic
• bridge pickup
• Quantum 7 (H) bridge pickupPassive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E,7B
• strings
• D'Addario® EXL110-7
• string gauge
• .010/.013/.017/.026/.036/.046/.059
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 48mm at NUT
  • b : Width
  • 68mm at 24F
  • c : Thickness
  • 19mm at 1F
  • d : Thickness
  • 21mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.

F107 bridge

The F107 bridge enriches sustain. String height adjustment can be done easily and independently.

Wizard II 3pc Maple neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability for demanding players.

Meranti body

The Meranti body provides a scooped mid-ranged sweet tone.

Quantum H-H pickups

The Quantum pickups have a quick low-end response to picking and are able to capture fast passages with precise note definition, while delivering a full-bodied mid-to-high range.
