SPECS

• neck type
• Wizard III7pc Maple/WalnutNeck-through
• top/back/body
• Poplar Burl (3mm) topAmerican Basswood wing body
• fretboard
• Ebony fretboardAcrylic & Abalone block inlay
• fret
• Jumbo Stainless Steel fretsPremium fret edge treatment
• number of frets
• 24
• bridge
• Edge bridge
• string space
• 10.8mm
• neck pickup
• DiMarzio® Air Norton™ (H) neck pickupPassive/Alnico
• bridge pickup
• DiMarzio® The Tone Zone® (H) bridge pickupPassive/Alnico
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL120
• string gauge
• .009/.011/.016/.024/.032/.042
• nut
• Locking nut
• hardware color
• Cosmo Black

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 58mm at 24F
  • c : Thickness
  • 19mm at 1F
  • d : Thickness
  • 21mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Wizard III 7pc Maple/Walnut neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability and features a two-octave 24-fret fretboard for a wide tonal range.

Jumbo Stainless Steel frets with Premium fret edge treatment

Stainless steel frets boast excellent corrosion resistance. The wide and tall fret-type offers a quick response and effortless articulation when playing chords and clear tone when playing single notes.
The Premium Fret Edge Treatment offers a super smooth, comfortable performance.

Poplar Burl top / American Basswood body

The Poplar Burl top features an exotic wood grain and the American Basswood body delivers a natural and flat tone.

DiMarzio® Air Norton™ / The Tone Zone® pickups

A pair of high-output DiMarzio® Air Norton™ and The Tone Zone® pickups provides a huge sound with a broad dynamic range.

Ebony fretboard

Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.

Neck-through Construction

The neck-through construction contributes to massive sustain and smooth access to high fretboard positions.

Luminescent side dot inlays

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.

Edge tremolo bridge

The masterpiece Edge bridge offers exceptional tuning stability, precise intonation adjustment, and playing comfort.

dyna-MIX10 switching system with Alter Switch

The dyna-MIX 10 offers ten sound variations and can easily switch from humbucker and single coil modes with the mini switch. The power Tap mode provides a realistic single coil sound despite its two humbucker pickup layout.
