SPECS

• neck type
• AZ Oval CRoasted Maple neck
• top/back/body
• Alder body
• fretboard
• Ebony fretboardReversed Sharktooth inlay
• fret
• Jumbo Stainless Steel frets
• number of frets
• 24
• bridge
• Gotoh® T1502 bridge
• string space
• 10.5mm
• neck pickup
• Fishman® Fluence™ Bernth Custom Series (H) neck pickupActive/Alnico
• bridge pickup
• Fishman® Fluence™ Bernth Custom Series (H) bridge pickupActive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL110
• string gauge
• .010/.013/.017/.026/.036/.046
• nut
• Graph Tech® nut
• hardware color
• Chrome

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 42mm at NUT
  • b : Width
  • 57mm at 24F
  • c : Thickness
  • 20.5mm at 1F
  • d : Thickness
  • 22.5mm at 12F
  • Radius :
  • 305mmR

SWITCHING SYSTEM

CONTROLS

Features

Oval C Roasted Maple neck

The Roasted Maple neck is heat-treated to increase stability, durability, moisture resistance and tolerance of temperature changes.

Ebony fretboard

Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.

Jumbo Stainless Steel frets

Stainless steel frets boast excellent corrosion resistance. The wide and tall fret-type offers a quick response and effortless articulation when playing chords and clear tone when playing single notes.

Fishman® Fluence™ Bernth Custom Series Humbacker pickups

Bernth's custom Fishman® Fluence™ set was designed to cover the widest possible tonal range, eliminating the need to switch guitars for different sounds and styles. From atmospheric cleans to searing modern metal tones, these pickups capture the full scope of his session and solo work with unmatched clarity and versatility.

Gotoh® MG-T locking machine heads

The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.

Gotoh® T1502 tremolo

The T1502 tremolo bridge features steel saddles and a die-cast zinc tremolo block for a quick response and improved articulation. The 10.5mm string spacing allows for easy picking across strings and its snap-in construction makes it easy to load a tremolo arm.

Fishman® Fluence™ Voicing switch on tone control (push/pull) for Bernth Signature Series pickups

The Voicing switch allows the pickups to switch between three musically complementary voices.

Bernth logo

Luminescent side dot inlays

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
