SPECS

• neck type
• Wizard II-75pc Maple/Walnut neck
• top/back/body
• Okoume body
• fretboard
• Ebony fretboardK-7 special inlay
• fret
• Jumbo frets
• number of frets
• 24
• bridge
• Lo-Pro Edge7 bridge w/U-bar
• string space
• 10.8mm
• neck pickup
• DiMarzio® Blaze™ (H) neck pickupPassive/Ceramic
• bridge pickup
• DiMarzio® Blaze™ (H) bridge pickupPassive/Ceramic
• factory tuning
• 1D,2A,3F,4C,5G,6D,7A
• strings
• D'Addario® EXL110-7
• string gauge
• .010/.013/.017/.026/.036/.046/.059
• nut
• Locking nut
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 48mm at NUT
  • b : Width
  • 68mm at 24F
  • c : Thickness
  • 19mm at 1F
  • d : Thickness
  • 21mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Wizard II-7 5pc Maple/Walnut neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability for demanding players.

Ebony fretboard

Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.

Jumbo frets

Jumbo frets contribute to smooth playability, especially for single-note playing.

DiMarzio® Blaze™ H-H pickups

DiMarzio® Blaze™ pickups were first introduced for our Universe guitars. With a scooped mid-range and just-right output level, they can handle everything from jazzy-clean tone to heavily distorted sound.

Gotoh® machine heads

Gotoh® machine heads provide superior precision, a smooth feel, and excellent tuning accuracy.

Lo-Pro Edge tremolo

The legendary Lo-Pro Edge bridge offers maximum playing comfort with its streamlined profile and recessed fine tuners. Locking studs contribute to tuning stability.

Luminescent side dot inlays

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
