SPECS

• neck type
• Super Wizard5pc Maple/Walnut neck
• top/back/body
• Basswood body
• fretboard
• Bound Rosewood fretboardWhite Sharktooth inlay
• fret
• Jumbo frets
• number of frets
• 24
• bridge
• Edge bridge
• string space
• 10.8mm
• neck pickup
• Infinity R (H) neck pickupPassive/Ceramic
• bridge pickup
• V8 (H) bridge pickupPassive/Alnico
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL120
• string gauge
• .009/.011/.016/.024/.032/.042
• nut
• Locking nut
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 58mm at 24F
  • c : Thickness
  • 17mm at 1F
  • d : Thickness
  • 19mm at 12F
  • Radius :
  • 430mmR

SWITCHING SYSTEM

CONTROLS

Features

Super Wizard 5pc Maple/Walnut neck

The Super Wizard 5pc Maple/Walnut neck provides extra-smooth playing.

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Jumbo frets

Jumbo frets contribute to smooth playability, especially for single-note playing.

Basswood body

The Basswood body delivers a natural and flat tone.

Infinity R / V8 pickups

Ibanez Infinity pickups deliver an accurate and tight sound with excellent dynamics. Even under heavy settings, they do not lose tonal clarity.

Gotoh® machine heads

Gotoh® machine heads provide superior precision, a smooth feel, and excellent tuning accuracy.

Edge tremolo

The masterpiece Edge bridge offers exceptional tuning stability, precise intonation adjustment, and playing comfort.
