SPECS

• neck type
• FLATVS-TECH WOOD Roasted Maple neck
• top/back/body
• Alder body
• fretboard
• Rosewood fretboardIvory dot inlay
• fret
• Medium fretsPrestige fret edge treatment
• number of frets
• 21
• bridge
• Gotoh® F1803 bridge
• string space
• 10.5mm
• neck pickup
• Seymour Duncan® FLAT5™ (H) neck pickupPassive/Alnico
• bridge pickup
• Seymour Duncan® FLAT5™ (S) bridge pickupPassive/Alnico
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL110
• string gauge
• .010/.013/.017/.026/.036/.046
• nut
• Bone nut
• hardware color
• Chrome

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 42mm at NUT
  • b : Width
  • 56mm at 21F
  • c : Thickness
  • 22mm at 1F
  • d : Thickness
  • 24.5mm at 12F
  • Radius :
  • 250mmR

SWITCHING SYSTEM

CONTROLS

Features

FLATV S-TECH WOOD Roasted Maple neck

The FLATV neck features a ’Soft V’ neck grip shape that blends the charm of a classic neck shape with a modern feel. This enables the neck to feel both substantial and comfortable to the player. The S-TECH Roasted Maple neck is constructed with 1 piece, and is the perfect combination of form and function.

Rosewood fretboard w/ Ivory dot

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Medium frets with Prestige fret edge treatment

Medium sized frets enhance the accuracy of your notes. Prestige Fret Edge Treatment guarantees effortlessly fast playing.

Alder body

The Alder body delivers a well-balanced bright tone, enriched resonance and sustain.

Seymour Duncan® FLAT5™ H-S pickups

Josh's signature pickup set from Seymour Duncan® features a vintage voiced neck humbucker pickup with a mounting ring that adds to the visual aesthetic of the ‘hot-rod' nature of this guitar, paired with a bridge pickup that is constructed with a mix of different types of Alnico magnets to best match the tone that Josh has relied on for years, and is able to capture guitar sounds that are both bright and fat. This pairing of the distinctly different pickups offers a unique tonal option in the middle position.

Gotoh® machine heads

Gotoh® machine heads provide super precision, smooth feel, and minimal back lush.

Gotoh® F1803 bridge

The Gotoh® F1803 bridge improves sustain and tuning stability.

Luminlay side dot inlays

The Luminlay side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
