SPECS

• neck type
• Atlas-55pc Panga Panga/Purpleheart neck w/KTS™ TITANIUM rods
• top/back/body
• Flamed Maple/Ash topAfrican Mahogany body
• fretboard
• Rosewood fretboardAvalone oval inlay
• fret
• Medium fretsPremium fret edge treatment
• number of frets
• 24
• bridge
• MR5S bridge
• string space
• 18mm
• neck pickup
• Aguilar® DCB neck pickupPassive
• bridge pickup
• Aguilar® DCB bridge pickupPassive
• equalizer
• Ibanez Custom Electronics 3-band EQ w/EQ bypass switch (passive tone control on treble pot), 3-way Mid frequency switch
• factory tuning
• 1G,2D,3A,4E,5B
• strings
• D'Addario® EXL165 + .130
• string gauge
• .045/.065/.085/.105/.130
• nut
• Graph Tech® BLACK TUSQ XL® nut
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 864mm/34"
  • a : Width
  • 45mm at NUT
  • b : Width
  • 74mm at 24F
  • c : Thickness
  • 19.5mm at 1F
  • d : Thickness
  • 21.5mm at 12F
  • Radius :
  • 305mmR

CONTROLS

FREQUENCY RESPONSE

Features

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Flamed Maple / Ash top & back / African Mahogany body

The Flamed Maple/Ash top offers a beautiful wood grain. The African Mahogany body delivers a rich mid-low end.

Aguilar® DCB pickups

The Aguilar® DCB pickups use the dual-ceramic bar design to capture all the detail and character of your tone. The pickup's uniform magnetic field ensures that no information is lost, making this a great pickup for dynamic playing styles.

Atlas 5pc Panga Panga/Purpleheart neck with KTS™ TITANIUM rods

The Atlas 5pc Panga Panga/Purpleheart neck provides a well-balanced note attack and tone with rich sustain.The neck is constructed with KTS™ TITANIUM reinforcement rods, increasing its stability and adding sustain.

Premium Fret Edge Treatment

Premium Fret Edge Treatment offer super smooth,comfortable performance.

Gotoh® machine heads

Gotoh machine heads provide super precision, an ultra smooth feel, and minimal back lush.

MR5S bridge

The MR5S bridge has adjustable saddles for variable string spacing by +/- 1.5mm, answering every bassist’s specific string spacing needs.

Ibanez Custom Electronics 3-band EQ w/EQ bypass switch & Mid frequency switch

Ibanez Custom Electronics 3-band EQ is our latest refinement on the concept of simple, straightforward, no-nonsense EQ control. The Boost and Cut for the Mid Control are each centered on slightly different frequencies, an innovation that delivers a preset range of the most favorable bass tones.
Precision tonal control, including a switch to choose passive-only operation. When the EQ bypass is activated, the treble tone control knob becomes the global tone control for the passive circuit.
