SPECS

• neck type
• Wizard5pc Maple/Walnut neck
• top/back/body
• Poplar Burl/Maple/Walnut/Curly Maple/Panga Panga (17mm) topAmerican Basswood body
• fretboard
• Ebony fretboardMother of Pearl Step off-set dot inlay
• fret
• Jumbo Stainless Steel fretsPremium fret edge treatment
• number of frets
• 24
• bridge
• Edge bridge
• string space
• 10.8mm
• neck pickup
• DiMarzio® Fusion Edge (H) neck pickupPassive/Ceramic
• bridge pickup
• DiMarzio® Fusion Edge (H) bridge pickupPassive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL120
• string gauge
• .009/.011/.016/.024/.032/.042
• nut
• Locking nut
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 58mm at 24F
  • c : Thickness
  • 18mm at 1F
  • d : Thickness
  • 20mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Wizard 5pc Maple/Walnut neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability for demanding players.

Jumbo Stainless Steel frets with Premium fret edge treatment

Stainless steel frets boast excellent corrosion resistance. The wide and tall fret-type offers a quick response and effortless articulation when playing chords and clear tone when playing single notes.
The Premium Fret Edge Treatment offers a super smooth, comfortable performance.

Poplar Burl/Maple/Walnut/Curly Maple/Panga Panga top / American Basswood body

The Poplar Burl/Maple/Walnut/Curly Maple/Panga Panga top flaunts a gorgeous wood grain. American Basswood body delivers a natural and flat tone.

DiMarzio® Fusion Edge pickups

Through close collaboration between Ibanez and DiMarzio®, Fusion Edge pickups have been engineered to produce a powerful, distinctive tone with a crisp, cutting high end, and a tight, compressed bottom end, minus any muddy mid-range.

Gotoh® machine heads

Gotoh® machine heads provide superior precision, a smooth feel, and excellent tuning accuracy.

Edge tremolo

The masterpiece Edge bridge offers exceptional tuning stability, precise intonation adjustment, and playing comfort.

Luminescent side dot inlays

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.

dyna-MIX10 switching system with Alter Switch

The dyna-MIX 10 offers ten sound variations and can easily switch from humbucker and single coil modes with the mini switch. The power Tap mode provides a realistic single coil sound despite its two humbucker pickup layout.
