SPECS

• neck type
• Wizard III-8 for Multi Scale5pc Maple/Walnut neck
• top/back/body
• Poplar Burl topNyatoh body
• fretboard
• Jatoba fretboardWhite Step off-set dot inlay
• fret
• Jumbo frets
• number of frets
• 24
• bridge
• Mono-rail bridge
• string space
• 10.8mm
• neck pickup
• Array 8 MS (H) neck pickupPassive/Ceramic
• bridge pickup
• Array 8 MS (H) bridge pickupPassive/Ceramic
• factory tuning
• 1D#,2A#,3F#,4C#,5G#,6D#,7A#,8F
• strings
• D'Addario® EXL120+.059+.080
• string gauge
• .009/.011/.016/.024/.032/.042/.059/.080
• hardware color
• Cosmo Black

NECK DIMENSIONS

• • Scale :
  • 692mm/27.2" - 648mm/25.5"
  • a : Width
  • 55mm at NUT
  • b : Width
  • 80mm at 24F
  • c : Thickness
  • 20mm at 1F
  • d : Thickness
  • 21.5mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.

Mono-rail bridge

Designed for both stability and sustain, the innovative Ibanez Mono-Rail bridge minimizes cross-talk between strings

Poplar Burl top / Nyatoh body

The Poplar Burl top features an exotic wood grain and the Nyatoh body provides a rich mid-low end.

Array-8 MS pickups

Ibanez Array pickups deliver a super tight tone with low noise that handle down-tuning perfectly.

Wizard III 5pc Maple/Walnut neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability and features a two-octave 24-fret fretboard for a wide tonal range.
