SPECS

• neck type
• JS3pc Maple/Bubinga neck
• top/back/body
• Alder body
• fretboard
• Rosewood fretboardMother of Pearl dot inlay
• fret
• Medium fretsPrestige fret edge treatment
• number of frets
• 24
• bridge
• Edge bridge
• string space
• 10.8mm
• neck pickup
• SUSTAINIAC® Driver neck pickup
• bridge pickup
• DiMarzio® Satchur8™ (H) bridge pickupPassive/Alnico
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL120
• string gauge
• .009/.011/.016/.024/.032/.042
• nut
• Locking nut
• hardware color
• Gold

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 42.8mm at NUT
  • b : Width
  • 56.4mm at 21F
  • c : Thickness
  • 20mm at 1F
  • d : Thickness
  • 22.3mm at 12F
  • Radius :
  • 250mmR

SWITCHING SYSTEM

CONTROLS

Features

3pc Maple/Bubinga neck

The Bubinga stripe provides stability and longer sustain.

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Medium frets with Prestige fret edge treatment

Medium sized frets enhance the accuracy of your notes. Prestige Fret Edge Treatment guarantees effortlessly fast playing.

Alder body

The Alder body delivers a well-balanced bright tone, enriched resonance and sustain.

SUSTAINIAC® Driver / DiMarzio® Satchur8™ pickups

The SUSTAINIAC® Driver in the neck position is wired to "Stealth PRO" preamp specially customized for Joe. It allows endless sustain and expands the range of expression dramatically with a 3-way Sustainiac mode selector. DiMarzio® Satchur8™ pickup fully supports Joe's versatile playing style and massive sound.

Gotoh® machine heads

Gotoh® machine heads provide superior precision, a smooth feel, and excellent tuning accuracy.

The masterpiece Edge bridge offers exceptional tuning stability, precise intonation adjustment, and playing comfort.

High-Pass filter on volume control

A high pass filter on the volume pot maintains highs at low volumes.

Sustainiac switch on tone control (push/pull)

Activate the Sustainiac switch and get an endless ringing note.

3-way mini switch for Sustainiac

Normal: Sustains the fundamental tone. Mix: Sustains the fundamental and overtone. Harmonic: Sustains the overtone.

Gold Finish
