SPECS

• neck type
• Super Wizard HP5pc Maple/Walnut neck
• top/back/body
• Ash body
• fretboard
• Bound Macassar Ebony fretboardWhite dot inlay
• fret
• Jumbo fretsPrestige fret edge treatment
• number of frets
• 24
• bridge
• Gibraltar Standard III bridge
• string space
• 10.8mm
• neck pickup
• DiMarzio® Fusion Edge (H) neck pickupPassive/Ceramic
• bridge pickup
• DiMarzio® Fusion Edge (H) bridge pickupPassive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL110
• string gauge
• .010/.013/.017/.026/.036/.046
• nut
• Graph Tech® BLACK TUSQ XL® nut
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 58mm at 24F
  • c : Thickness
  • 17mm at 1F
  • d : Thickness
  • 19mm at 12F
  • Radius :
  • 430mmR

SWITCHING SYSTEM

CONTROLS

Features

Super Wizard 5pc Maple/Walnut neck

The Super Wizard 5pc Maple/Walnut neck provides extra-smooth playing.

Macassar Ebony fretboard

Macassar Ebony produces tight lows and mid range along with strong attack in the highs and quick response with rich sustain.

Ash body

The Ash body delivers a pleasant brightness and rich sustain.

Gibraltar Standard III bridge

The Gibraltar Standard III bridge, featuring a redesigned baseplate and saddles, offers enhanced playing comfort while ensuring optimal string vibration transfer.

DiMarzio® Fusion Edge Pickups

Through close collaboration between Ibanez and DiMarzio® Fusion Edge pickups have been engineered to produce a powerful, distinctive tone with a crisp, cutting high end, and a tight, compressed bottom end, minus any muddy mid-range.

Gotoh® MG-T locking machine heads

The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.
