SPECS

• neck type

• GRXMaple neck

• top/back/body

  Quilted Maple Art Grain (Basswood) topPoplar body

• fretboard

  Jatoba fretboardWhite dot inlay

• fret

  Medium frets

• number of frets

  22

• bridge

  T106 bridge

• string space

  10.5mm

• neck pickup

  Infinity R (H) neck pickupPassive/Ceramic

• middle pickup

  Infinity RS (S) middle pickupPassive/Ceramic

• bridge pickup

  Infinity R (H) bridge pickupPassive/Ceramic

• factory tuning

  1E,2B,3G,4D,5A,6E

• string gauge

  .009/.011/.016/.024/.032/.042

• hardware color

  Chrome

NECK DIMENSIONS

• • Scale :

    648mm/25.5"

  • a : Width

    42mm at NUT

  • b : Width

    57mm at 22F

  • c : Thickness

    19.5mm at 1F

  • d : Thickness

    21.5mm at 12F

  • Radius :

    305mmR

SWITCHING SYSTEM

CONTROLS

Features

Maple neck

The Maple neck provides stability and bright tonal character.

T106 tremolo bridge

The T106 tremolo bridge with 6 independent saddles makes precise height and intonation adjustment of each string easy.

Mono-unit output jack

The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.

Infinity R H-H pickups

Ibanez Infinity pickups deliver an accurate and tight sound with excellent dynamics. Even under heavy settings, they do not lose tonal clarity.

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
