SPECS

• neck type
• AZ Oval CS-TECH WOOD Roasted Maple neck
• top/back/body
• Flamed Maple (4mm) topAlder body
• fretboard
• Rosewood fretboardAbalone dot inlay
• fret
• Jumbo Stainless Steel fretsPrestige fret edge treatment
• number of frets
• 22
• bridge
• Gotoh® T1702B bridge
• string space
• 10.5mm
• neck pickup
• TQM-S (S) neck pickupPassive/Ceramic
• middle pickup
• TQM-S (S) middle pickupPassive/Ceramic
• bridge pickup
• TQM-H (H) bridge pickupPassive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL110
• string gauge
• .010/.013/.017/.026/.036/.046
• nut
• Bone nut
• hardware color
• Chrome

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 42mm at NUT
  • b : Width
  • 56.4mm at 22F
  • c : Thickness
  • 20.5mm at 1F
  • d : Thickness
  • 22.5mm at 12F
  • Radius :
  • 228mmR to 305mmR COMPOUND

SWITCHING SYSTEM

CONTROLS

Features

Oval C S-TECH WOOD Roasted Maple neck

The S-TECH special roasted treatment increases the wood's stability, durability, water resistance and tolerance of temperature changes. The neck is sealed with an oil finish which helps make it feel similar to a well-played guitar neck.

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Flamed Maple (4mm) top / Alder body

The Flamed Maple top displays a beautiful wood grain. The Alder body delivers a well-balanced bright tone, enriched resonance and sustain.

Ibanez TQM Pickups

Tom Quayle and Ibanez teamed up to develop the TQM-S single coil and TQM-H humbucker pickups.  These pickups precisely reflect subtle playing nuances and produce a natural clean voicing that works well with various effect pedals.  The TQM pickups are mandatory to realize the "Tom Quayle signature sound".

Gotoh® T1702B tremolo

The T1702B tremolo bridge provides quick response and improved articulation. The 10.5mm string spacing allows for easy picking across strings and its snap-in construction makes it easy to load a tremolo arm. The tremolo block and saddles are made of brass, facilitating better overall resonance.

dyna-MIX9 switching system with Alter Switch

The dyna-MIX 9 offers nine sound variations and can switch between humbucker and single coil modes with just a flick of the mini switch. One mode even simulates a humbucking sound from the combination of two single coil pickups.

Super All Access Neck Joint

The Super All Access Neck Joint increases playability and allows for easy access to the higher frets.

Luminlay side dot inlays

The Luminlay side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
