SPECS

• neck type
• GRGMaple neck
• top/back/body
• Poplar body
• fretboard
• Bound Purpleheart fretboardWhite Sharktooth inlay
• fret
• Medium frets
• number of frets
• 24
• bridge
• T102 bridge
• string space
• 10.5mm
• neck pickup
• Infinity R (H) neck pickupPassive/Ceramic
• middle pickup
• Infinity RS (S) middle pickupPassive/Ceramic
• bridge pickup
• Infinity R (H) bridge pickupPassive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E
• string gauge
• .009/.011/.016/.024/.032/.042
• hardware color
• Chrome

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 58mm at 24F
  • c : Thickness
  • 19.5mm at 1F
  • d : Thickness
  • 21.5mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Maple neck

The Maple neck provides stability and bright tonal character.

Infinity RS / Infinity R S-S-H pickups

Ibanez Infinity pickups deliver an accurate and tight sound with excellent dynamics. Even under heavy settings, they do not lose tonal clarity.

T102 tremolo

The T102 bridge with 10.5mm string spacing allows easier picking across strings.

Purpleheart fretboard

The Purpleheart fretboard emphasizes the beauty and the rich tonal character of this guitar.

Mono-unit output jack

The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.
