SPECS

• neck type
• Wizard-95pc Maple/Walnut neck
• top/back/body
• Poplar Burl topNyatoh body
• fretboard
• Macassar Ebony fretboardWhite dot inlay
• fret
• Jumbo frets
• number of frets
• 24
• bridge
• Gibraltar Standard II-9 bridge
• string space
• 10.8mm
• neck pickup
• Fishman® Fluence™ Modern Humbucker Alnico 9 (H) neck pickupActive/Alnico
• bridge pickup
• Fishman® Fluence™ Modern Humbucker Ceramic 9 (H) bridge pickupActive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E,7B,8F#,9C#
• strings
• D'Addario® EXL120-7 + .075/.090
• string gauge
• .009/.011/.016/.024/.032/.042/.054/.075/.090
• nut
• Graph Tech® nut
• hardware color
• Cosmo Black

NECK DIMENSIONS

• • Scale :
  • 712mm/28"
  • a : Width
  • 62mm at NUT
  • b : Width
  • 88mm at 24F
  • c : Thickness
  • 21.5mm at 1F
  • d : Thickness
  • 23.5mm at 12F
  • Radius :
  • 950mmR

SWITCHING SYSTEM

CONTROLS

Features

Wizard 5pc Maple/Walnut neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability for demanding players.

Macassar Ebony fretboard

Macassar Ebony produces tight lows and mid range along with strong attack in the highs and quick response with rich sustain.

Poplar Burl top / Nyatoh body

The Poplar Burl top features an exotic wood grain and the Nyatoh body provides a rich mid-low end.

Fishman® Fluence™ Modern Humbucker Alnico / Fluence™ Modern Humbucker Ceramic pickups

The Fishman® Fluence™ Modern Humbucker pickups provide an aggressive tone and a powerful attack without excess noise.

Gibraltar Standard II bridge

The Gibraltar Standard II is a simple fixed bridge designed to provide optimal transfer of each string's vibration and its smooth surface maximizes playing comfort.

Coil-tap switch

The coil tap switch adds sound and tonal variations for both pickups.

Fishman® Fluence™ Voicing switch on volume control (push/pull)

The Voicing switch allows the pickups to switch from a modern, active high output sound to a crisp, clean and fluid sound.
