SPECS

• neck type
• Wizard II-7Roasted Maple neck
• top/back/body
• Nyatoh body
• fretboard
• Ebony fretboard
• fret
• Jumbo frets
• number of frets
• 24
• bridge
• Mono-rail bridge
• string space
• 10.8mm
• neck pickup
• DiMarzio® D Activator 7™ (H) neck pickupPassive/Ceramic
• bridge pickup
• DiMarzio® D Activator 7™ (H) bridge pickupPassive/Ceramic
• factory tuning
• 1D,2A,3F,4C,5G,6D,7A
• strings
• D'Addario® EXL110-7
• string gauge
• .010/.013/.017/.026/.036/.046/.059
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 673mm/26.5"
  • a : Width
  • 48mm at NUT
  • b : Width
  • 68mm at 24F
  • c : Thickness
  • 19mm at 1F
  • d : Thickness
  • 21mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Nyatoh body

Nyatoh used as the body wood provides a rich mid-low end.

DiMarzio® D Activator™ pickups

DiMarzio® D Activator™ pickups have a powerful, clean, and open sound with excellent harmonic overtones and very tight low-end response.

26.5 inch scale

Its extra long 26.5" scale and ability to accurately intonate heavier string gauges, make it the perfect beast for down-tuned metal.

Mono-rail bridge

Designed for both stability and sustain, the innovative Ibanez Mono-Rail bridge minimizes cross-talk between strings

Ebony fretboard

Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.

Luminescent side dot inlays

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.

Gotoh® MG-T locking machine heads

The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.

Wizard II Roasted Maple neck

The Roasted Maple neck is heat-treated to increase stability, durability, moisture resistance and tolerance of temperature changes.The Graphite reinforcement rods provides massive sustain and excellent stability.
