SPECS

• neck type
• PGM5pc Maple/Walnut
• top/back/body
• American Basswood body
• fretboard
• Rosewood fretboardWhite dot inlay
• fret
• Medium fretsPremium fret edge treatment
• number of frets
• 22
• bridge
• F106 bridge
• string space
• 10.5mm
• neck pickup
• DiMarzio® Air Classic™ (H) neck pickupAlnico/Passive
• middle pickup
• DiMarzio® PGM™ (S) middle pickupAlnico/Passive
• bridge pickup
• DiMarzio® Air Classic™ (H) bridge pickupAlnico/Passive
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL110
• string gauge
• .010/.013/.017/.026/.036/.046
• hardware color
• Gold

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 57mm at 22F
  • c : Thickness
  • 20mm at 1F
  • d : Thickness
  • 22mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

5pc Maple/Walnut neck

The 5pc Maple/Walnut neck provides tonal clarity and superior attack.

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Medium frets with Premium fret edge treatment

Medium sized frets enhances the accuracy to your notes.
The Premium Fret Edge Treatment offers a super smooth, comfortable performance.

American Basswood body

The American Basswood body delivers a natural and flat tone.

DiMarzio® Air Classic™ (H) / DiMarzio® PGM™ (S) / DiMarzio® Air Classic™ (H) pickups

DiMarzio® Air Classic™ pickup combining vintage voicing with modern technology delivers an incredible touch-sensitive sound. DiMarzio® PGM single-coil middle pickup provides a perfect mix of vintage and modern sounds.

Gotoh® MG-T locking machine heads

The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.

F106 bridge

The F106 bridge enriches sustain. String height adjustment can be done easily and independently.
