SPECS

• neck type
• Wizard IIIMaple neck
• top/back/body
• Meranti body
• fretboard
• Jatoba fretboardSharktooth inlay
• fret
• Jumbo frets
• number of frets
• 24
• bridge
• Edge-Zero II bridge
• string space
• 10.8mm
• neck pickup
• Quantum (S) neck pickupPassive/Alnico
• middle pickup
• Quantum (S) middle pickupPassive/Alnico
• bridge pickup
• Quantum (H) bridge pickupPassive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL120
• string gauge
• .009/.011/.016/.024/.032/.042
• nut
• Locking nut
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 43mm at NUT
  • b : Width
  • 58mm at 24F
  • c : Thickness
  • 19mm at 1F
  • d : Thickness
  • 21mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.

Mono-unit output jack

The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.

Edge-Zero II tremolo bridge

The Edge Zero II bridge design features a lower profile tremolo for playing comfort and stud lock function for stable tuning.

Wizard III Maple neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability and features a two-octave 24-fret fretboard for a wide tonal range.

Quantum S-S-H pickups

The Quantum pickups provide accelerated bass response for exceptionally fast tracking of high-speed staccato riffing with crushing mid range and precise high-end articulation.

Meranti body

The Meranti body provides a scooped mid-range with a sweet tone.
