SPECS

• neck type

• Wizard C3pc Roasted Maple/Bubinga neck

• top/back/body

  Nyatoh body

• fretboard

  Roasted Birdseye Maple fretboardMother of Pearl Step off-set dot inlay

• fret

  Jumbo Stainless Steel frets

• number of frets

  24

• bridge

  Ibanez Mono-Tune bridge

• string space

  10.8mm

• neck pickup

  R1 (S) neck pickupPassive/Ceramic

• middle pickup

  R1 (S) middle pickupPassive/Ceramic

• bridge pickup

  Q58 (H) bridge pickupPassive/Ceramic

• factory tuning

  1E,2B,3G,4D,5A,6E

• strings

  D'Addario® EXL110

• string gauge

  .010/.013/.017/.026/.036/.046

• hardware color

  Cosmo black

NECK DIMENSIONS

• • Scale :

    648mm/25.5"

  • a : Width

    42mm at NUT

  • b : Width

    57mm at 24F

  • c : Thickness

    21mm at 1F

  • d : Thickness

    22mm at 12F

  • Radius :

    305mmR

SWITCHING SYSTEM

CONTROLS

Features

Wizard C 3pc Roasted Maple/Bubinga neck

To meet the demand of various playing styles, this Wizard C neck has a very neutral shape – it’s not too thick, too thin, or too flat. The 3pc Roasted Maple/Bubinga construction also offers great stability and long-term durability.

Nyatoh body

Nyatoh used as the body wood provides a rich mid-low end.

R1 / Q58 S-S-H pickups

The R1 / Q58 pickup combo is designed specifically for use in headless guitars. They provide a clearly defined sound, facilitating excellent tonal balance through all frequencies. The lows are powerful without being muddy, and the highs are bright and clear, but never harsh. As a result, every single note within the chord structure is well defined, and clearly audible. These pickups, with their tonal balance, and extremely low noise performance, work extremely well with both digital and analog effects.

Custom string lock

This custom string lock is one-piece unit that features very simple construction. This means the hardware requires less maintenance, is highly durable, and allows for very easy string changes. Additionally, no proprietary string is required, so you can continue to use your favorite gauge and brand.

Mono-Tune bridges

The Mono-Tune bridges offer a wide intonation range so that you can easily set the instrument up for tuning down a whole step or even further. The string height is also easily adjustable, and each saddle generally has less material, which leads to more natural and organic tone.

dyna-MIX9 switching system with Alter Switch

The dyna-MIX 9 offers nine sound variations and can switch between humbucker and single coil modes with just a flick of the mini switch. One mode even simulates a humbucking sound from the combination of two single coil pickups.

Roasted Birdseye Maple fretboard

The beautiful Birdseye Maple fretboard imbues this model with an exotic appearance . The fretboard is heat-treated for a balanced attack and rich sustain.

Jumbo Stainless Steel frets

Stainless steel frets boast excellent corrosion resistance. The wide and tall fret-type offers a quick response and effortless articulation when playing chords and clear tone when playing single notes.

Ergonomic body design

The body features a number of strategically placed curves on both the top and back of the instrument. This complex, yet sophisticated design provides maximum playing comfort.

Compact and light-weight, yet resonant body

While it is really compact and light-weight, its non-chambered, solid body provides great sound with rich woody tones.

Luminescent side dot inlays

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
