SPECS

• neck type
• Wizard II-73pc Maple neck
• top/back/body
• Meranti body
• fretboard
• Jatoba fretboardWhite dot inlay
• fret
• Jumbo frets
• number of frets
• 24
• bridge
• Edge-Zero II-7 bridge
• string space
• 10.8mm
• neck pickup
• Quantum 7 (H) neck pickupPassive/Ceramic
• bridge pickup
• Quantum 7 (H) bridge pickupPassive/Ceramic
• factory tuning
• 1E,2B,3G,4D,5A,6E,7B
• strings
• D'Addario® EXL120-7
• string gauge
• .009/.011/.016/.024/.032/.042/.054
• nut
• Locking nut
• hardware color
• Black

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 48mm at NUT
  • b : Width
  • 68mm at 24F
  • c : Thickness
  • 19mm at 1F
  • d : Thickness
  • 21mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.

Mono-unit output jack

The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.

Wizard II 3pc Maple neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability for demanding players.

Edge-Zero II tremolo bridge

The Edge Zero II bridge design features a lower profile tremolo for playing comfort and stud lock function for stable tuning.

Quantum H-H pickups

The Quantum pickups have a quick low-end response to picking and are able to capture fast passages with precise note definition, while delivering a full-bodied mid-to-high range.
