SPECS

• neck type
• SRC65pc Jatoba/Walnut neck
• top/back/body
• Okoume body
• fretboard
• Rosewood fretboardAbalone Step off-set dot inlay
• fret
• Medium frets
• bridge
• Mono-rail bridge
• string space
• 10.8mm
• neck pickup
• Bartolini® BH2 neck pickupPassive
• bridge pickup
• Bartolini® BH2 bridge pickupPassive
• equalizer
• Ibanez Custom Electronics 3-band EQ w/EQ bypass switch (passive tone control on treble pot), 3-way Mid frequency switch
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL156
• string gauge
• .024/.034/.044/.056/.072/.084
• hardware color
• Cosmo black

NECK DIMENSIONS

• • Scale :
  • 762mm/30" - 724mm/28.5"
  • a : Width
  • 42mm at NUT
  • b : Width
  • 58mm at 22F
  • c : Thickness
  • 19.5mm at 1F
  • d : Thickness
  • 21.5mm at 12F
  • Radius :
  • 400mmR

CONTROLS

FREQUENCY RESPONSE

Features

5pc Jatoba/Walnut neck

The 5pc Jatoba/Walnut neck provides tonal clarity and superior attack.

Multi scale

The multi scale construction equalizes tension of each string and it helps to create a more ”alive”, open tone. But the design also improves player comfort. The multi scale construction ergonomically coordinates with the way a player's hand angles as it moves up and down the neck, facilitating quick, comfortable playing action.

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Okoume body

The Okoume body provides a bright and solid sound.

Bartolini® BH2 pickups

The Bartolini® BH2 pickups provide a tight bottom-end, punchy mid-range, and smooth response. The dual-coil style configuration maximizes articulation and a long blade pole piece widens the magnetic field, providing balanced string-to-string pickup response.

Mono-rail bridge

Designed for both stability and sustain, the innovative Ibanez Mono-Rail bridge minimizes cross-talk between strings

Ibanez Custom Electronics 3-band EQ w/EQ bypass switch(passive tone control on treble pot) & 3-way Mid frequency switch

The Ibanez Custom Electronics 3-band EQ is our latest refinement on the concept of simple, straightforward, no-nonsense EQ control. The Boost and Cut for the Mid Control are each centered on slightly different frequencies, an innovation that delivers a preset range of the most favorable bass tones.
The EQ bypass control offers precision tonal adjustments, including a switch to choose passive-only operation. When the EQ bypass is activated, the treble tone control knob becomes the global tone control for the passive circuit.
The 3-way Mid frequency switch allow players to change the mid-tone between 250, 450, and 700 Hz.
