SPECS

• neck type
• Wizard III-8 for Multi Scale5pc Maple/Walnut neck
• top/back/body
• Nyatoh body
• fretboard
• Macassar Ebony fretboardWhite Step off-set dot inlay
• fret
• Jumbo frets
• number of frets
• 24
• bridge
• Mono-rail bridge
• string space
• 10.8mm
• neck pickup
• Fishman® Fluence™ Modern Humbucker Alnico 9 (H) neck pickupActive/Alnico
• bridge pickup
• Fishman® Fluence™ Modern Humbucker Ceramic 9 (H) bridge pickupActive/Ceramic
• factory tuning
• 1D#,2A#,3F#,4C#,5G#,6D#,7A#,8F
• strings
• D'Addario® EXL120-8
• string gauge
• .009/.011/.016/.024/.032/.042/.054/.065
• hardware color
• Gold

NECK DIMENSIONS

• • Scale :
  • 692mm - 648mm/27.2" - 25.5"
  • a : Width
  • 55mm at NUT
  • b : Width
  • 80mm at 24F
  • c : Thickness
  • 20mm at 1F
  • d : Thickness
  • 21.5mm at 12F
  • Radius :
  • 400mmR

SWITCHING SYSTEM

CONTROLS

Features

Wizard III 5pc Maple/Walnut neck

Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability and features a two-octave 24-fret fretboard for a wide tonal range.

Macassar Ebony fretboard

Macassar Ebony produces tight lows and mid range along with strong attack in the highs and quick response with rich sustain.

Nyatoh body

Nyatoh used as the body wood provides a rich mid-low end.

Fishman® Fluence™ Modern Humbucker Alnico / Fluence™ Modern Humbucker Ceramic pickups

The Fishman® Fluence™ Modern Humbucker pickups provide an aggressive tone and a powerful attack without excess noise.

Gotoh® MG-T locking machine heads

The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.

Mono-rail bridge

Designed for both stability and sustain, the innovative Ibanez Mono-Rail bridge minimizes cross-talk between strings

Coil-tap switch

The coil tap switch adds sound and tonal variations for both pickups.

Fishman® Fluence™ Voicing switch on volume control (push/pull)

The Voicing switch allows the pickups to switch from a modern, active high output sound to a crisp, clean and fluid sound.
