SPECS

• neck type
• AZ Oval C Roasted Maple neck
• top/back/body
• American Basswood body
• fretboard
• Ebony fretboardTree of Death inlay
• fret
• Jumbo Stainless Steel frets
• number of frets
• 24
• bridge
• Gotoh® T1502 tremolo bridge
• string space
• 10.5mm
• neck pickup
• Fishman® Fluence™ Tim Henson Signature Series (H) neck pickupActive/Alnico
• bridge pickup
• Fishman® Fluence™ Tim Henson Signature Series (H) bridge pickupActive/Alnico
• factory tuning
• 1E,2B,3G,4D,5A,6E
• strings
• D'Addario® EXL110
• string gauge
• .010/.013/.017/.026/.036/.046
• nut
• Graph Tech®
• hardware color
• Chrome

NECK DIMENSIONS

• • Scale :
  • 648mm/25.5"
  • a : Width
  • 42mm at NUT
  • b : Width
  • 57mm at 24F
  • c : Thickness
  • 20.5mm at 1F
  • d : Thickness
  • 22.5mm at 12F
  • Radius :
  • 305mmR

SWITCHING SYSTEM

CONTROLS

Features

Oval C Roasted Maple neck

The Roasted Maple neck is heat-treated to increase stability, durability, moisture resistance and tolerance of temperature changes.

Ebony fretboard

Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.

American Basswood body

The American Basswood body delivers a natural and flat tone.

Fishman® Fluence™ Tim Henson Signature Series pickups

Tim's signature Fishman® Fluence™ pickups span the entire range of aggressive lead and rhythm tones to the cleanest of clean single coil combinations, even touching on sounds Tim was previously only able to produce with his acoustic guitars.
Neck Pickup Voice 1: Thick and smooth neck humbucker / Voice 2: Hyper-clean, nylon string surrogate/ Voice 3: Tim's fluid neck single coil
Bridge Pickup Voice 1: Based on Fishman®'s hot-rodded Classic voice, the quintessential lead tone of generation / Voice 2: Combination of Tim's favorite bridge humbuckers / Voice 3: Tim's ideal single coil combination tone when used in conjunction with neck coil

Gotoh® T1502 tremolo

The T1502 tremolo bridge features steel saddles and a die-cast zinc tremolo block for a quick response and improved articulation. The 10.5mm string spacing allows for easy picking across strings and its snap-in construction makes it easy to load a tremolo arm.

Fishman® Fluence™ Voicing switch on tone control (push/pull) for Tim Henson Signature Series pickups

The Voicing switch allows the pickups to switch between three musically complementary voices.

Luminescent side dot inlays

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
