SPEC
neck type    SRMS6 for Multi Scale5pc Jatoba/Walnut neck
top/back/body    Poplar Burl topOkoume body
fretboard    Bound Panga Panga fretboardAcrylic special inlay
fret    Medium frets
number of frets    24
bridge    MR5S bridge
string space    16.5mm
neck pickup    Bartolini® BH2 neck pickupPassive
bridge pickup    Bartolini® BH2 bridge pickupPassive
equaliser    Ibanez Custom Electronics 3-band EQ w/ EQ bypass switch (passive tone control on treble pot) & 3-way Mid frequency switch
factory tuning    1C,2G,3D,4A,5E,6B
strings    D'Addario® EXL170-5SL + 0.32
string gauge    .032/.045/.065/.080/.100/.130
hardware color    Black

NECK DIMENSIONS
Scale :    901.7mm/35.5" - 854.7mm/33.6"
a : Width    54mm at NUT
b : Width    83mm at 24F
c : Thickness    19.5mm at 1F
d : Thickness    23mm at 12F
Radius :    400mmR

CONTROLS
